Our commercial tree chipper is a heavy-duty industrial machine specifically engineered for processing entire trees, large branches, and woody biomass into uniform wood chips. As a leading whole tree chipper for sale provider, we offer a commercial tree chipper that combines robust power systems with high-capacity feeding mechanisms, making it the ultimate solution for forestry logging operations, biomass energy production, wood recycling projects, and land clearing applications where a commercial tree chipper is essential.
| Whole Tree Chipper For Sale- Commercial Tree Chipper | ||
| Specifications | Imperial (in) |
|
| Operating Length | 46′ 10″ | 1430 cm |
| Operating Width | 10′2″ | 310 cm |
| Operating Height | 15′ 9″ | 480 cm |
| Travel Length | 38′ 5″ | 1170cm |
| Travel Width | 10′ 2″ | 310 cm |
| Travel Height | 11′ 9″ | 360 cm |
| Machine Weight | 67，240 lbs | 30500 kg |
| Engine | ||
| Cummins QSK-19 diesel engine, 760 hp/567 kW | Cummins QSK-19 diesel engine, 760 hp/567 kW | |
| Clutch | PT Tech 14 | PT Tech14 |
| Fuel Tank Capacity | 317 US gal | 1200 L |
| Main Hydraulic Tank Capacity | 92.5 US gal | 350 L |
| Feed Chain | 4 sections, full hopper width | 4 sections, full hopper width |
| Feed Opening (w x h) | 55.1″ x 33.5″ | 140 x 85 cm |
| Feed Conveyor Width | 4′ 7″ | 140 cm |
| Compression Roll Diameter | 28.7″ | 73 cm |
| Rotor Width | 55.1″ | 140cm |
| Rotor Diameter | 41.3” | 105 cm |
| Rotor Shaft Size | 6.3″ @ bearing, 7.3″ @ center | 160 mm @ bearing, 185 mm @ center |
| Bit Size (w x h) | 2.5″ x 4.5″ | 63 x 114 mm |
| Number of Bits | 23 drum rotor, 8 throwing knives | 23 drum rotor, 8 throwing knives |
| Rotor Speed | 900r/min @ 1800 rpm | 900r/min @ 1800 rpm |
| Number of Grate Sections | 2 | 2 |
| Total Grate Area | 29 ft² | 2.7 m² |
| Grate Coverage | 174° | 174° |
| Grate Thickness | 3/4″ | 19 mm |
| Discharge Conveyor Width | 3′ 7″ | 140 cm |
| Folding Discharge Conveyor Hight | 15′ 9″ | 480 cm |
| Conveyor Speed | 500 or 600 fpm | 152 or 183 mpm |
| Volume | 140 yd³ | 107 m3 |
| Weight | 30.5 tons | 30.5tonnes |
Applications of Tree Shredders
Land Clearing: Efficiently remove tree stumps and roots in land development or construction projects. Our tree shredders are ideal for preparing sites for new construction or landscaping projects.
Forestry Operations: Post-logging treatment of tree stumps and timber debris, reducing waste and improving forest management efficiency.
Landscaping: Remove unsightly tree stumps to enhance the aesthetics of residential, commercial, or public spaces. Our commercial tree shredders provide clean, professional results.
Urban Tree Removal: Safely remove tree stumps in urban areas without damaging surrounding infrastructure or the landscape.
Why Choose Our Tree Shredders?
Customizable Solutions: We customize machine specifications (power, shredding capacity, mobility) to meet specific project needs. We offer both trailer-mounted and self-propelled tree shredders.
Reliable After-Sales Service: A global network of service centers, ample spare parts supply, and technical support ensure minimal downtime for your commercial tree shredders.
Environmental Sustainability: Transform wood waste into valuable mulch or compost, reducing landfill volume and promoting circular economy practices.
Main Features and Options
1. Diesel Engine: Cummins QSK-19 diesel engine, 760 hp/567 kW
2. Hydraulic Configuration:
Load-sensitive piston pump (Made in China);
High-pressure output clutch (Made in the USA);
Clutch hydraulic control system (Made in the USA);
Feed system built-in motor (Made in China), feed piston motor (Made in China), discharge cycloidal motor (Made in China); Adjustable feed and discharge speeds;
Hydraulic control system: Solenoid valves, track proportional valves (Made in China), 9 valves on the main unit, 1 valve dedicated to the clutch (valve core from the USA);
1200-liter diesel tank;
350-liter hydraulic oil tank (heating system optional).
3. Electrical Configuration: Siemens PLC, Schneider Electric, Taiwan Yu-Ding remote control, 10-inch remote industrial screen (-25-55℃); standard control cables;
4. Rotor Configuration:
4 sets of 2-blade 360-H12 rotor blades, rotor bearings (SKF); rotor length 1400 mm, diameter 1050 mm;
