GENERAL DIMENSIONS
Transport Length:9200mm
Transport Width: 2200mm
Transport Height:2530mm
Engine: 200KW
Weight: 18100KG
Rotor Dimensions: Cutting width 1000mm, rotor diameter 1100mm,
9 flying knives/6 flying knives
Feed Width: 1000mm
Conveyor Dimensions: 1m × 10m
Discharge Height: 4.5m

CHIP DRUM OPTION
Millbox opening: 39.4″ x21.3″ (100 cm x 54cm)
Drum diameter: 43.3″ (110 cm)
Number of knives:6
Depth of cut: Ranging from .125″ to 1″ (.3 cm to 2.5 cm)

ELECTRIC MOTORS
feed motor horsepower: 7.5kw

feed motor horsepower: 7.5kw
feed motor horsepower: 7.5kw
Discharge motor horsepower: 4kw

Conveyor motorhorsepower: 5.5kw
Voltage: 380 V/460 V
Frequency: 50 Hz/60 Hz
Phase: Three phases
Enclosure: TEFC (totally enclosed, fan-cooled)

CONVEYOR
Belt width: 39.4″ (100 cm)
Belt design: 3-ply – 330# with V-cleat
Belt length: 78.7′ (20 m)

HYDRAULIC PUMP STATION
Tank capacity: 15.9 gal (60L)

INFEED CONVEYOR
Feed table width: 39.4″ (1m)
Feed table length: 15′ (4.6 m)
Loading height: 6.5′ (2 m)

CONTROL PANEL OPTIONS
VFD (variable frequency drive) panel: 380 V or 460 V, NEMA Type
5 enclosure
Soft-start starter panel: 380 V or 460 V, NEMA Type 4 enclosure

INFEED ROLLER
Max feed height: 21.3″ (54cm)
Infeed roller diameter: 11.6″ (29.5 cm)

CONTROLS
Stationary: Side-mounted LCD control station
Remote: Multifunction with built-in LCD display, max 300′ (91.4 m)
operating range

DUPLEX DRUM OPTION
Millbox opening: 39.4″ x 21.3″ (100 cm x 54 cm)
Drum diameter: 43.3″ (1100 cm)
Number of hammers: 19
